Disc Elevator Gearless Machine Rail Installation

Payment Type: T/T
Incoterm: CFR,CIF
Min. Order: 1 Piece/Pieces
Delivery Time: 20 Days

Basic Info

Model No.: Rail Installation

Type: Driving System

Load Capacity: 1000kg

Persons: 11-20

Speed: 1.00-2.00m/s, 1m/s 1.75m/s

Drive Mode: AC

Control Type: Microcomputer Frequency Control

Roping: 2:1

Capacity: 800kg | 1000kg

Traction Sheave Dia.: 480mm

Rope: 6*ø8mm

Pitch: 11.5mm

Other Groove Number: On Request

New Arrival: YES

Rail Installation Available: YES

Voltage: 3 Phase AC340V

Additional Info

Packaging: Export Packing

Productivity: 100,000pcs

Brand: Customer Name

Transportation: Ocean,Land,Air

Place of Origin: CHINA

Supply Ability: Quantity Production

Certificate: CE, Gost-R, SASO, VOC, KTL, UL, CSA

HS Code: 8425319000

Port: Ningbo,Shanghai

Product Description

Disc Elevator Gearless Machine Rail Installation


Disc Elevator Gearless Machine Rail Installation


Max. Static Load

3000kg

Weight

500kg

Duty

S5-60%ED

Insulation Class

155(F)

Brake

2*DZD2 | brake torque: 2*857 N.m | Current: 2*1.19A | Voltage: DC110V

Color

Blue | Gray | Black

Matching Inverter

Monarch | STEP | Optimax | SIEI | FUJI | YASKAWA | Emerson | Blue Light

Encoder

Machine is coming with Heidenhain ERN1387, ERN1321 & ECN1313 as TWO options

Machine Arrangement

MRL | MR

Rail Installation

Available

Voltage

3 Phase AC340V

Motor Poles

10



Part No.

Roping

Capacity

Speed

Motor

Traction Sheave

Power

Current

Diameter

Rope

Pitch

GLM800-100-D6R2H

2:1

800kg

1m/s

4.6kW

11.5A

480mm

6*ø8mm

11.5mm

GLM800-175-D6R2H

2:1

800kg

1.75m/s

8kW

20.5A

480mm

6*ø8mm

11.5mm

GLM1000-100-D6R2H

2:1

1000kg

1m/s

5.7kW

14.5A

480mm

6*ø8mm

11.5mm

GLM1000-175-D6R2H

2:1

1000kg

1.75m/s

10kW

27A

480mm

6*ø8mm

11.5mm


Diverting Pulley as an option at extra cost


We carry high quality Disc Gearless Machine
for all major elevator and escalator brands

for OTIS Elevators, ThyssenKrupp Elevators, Schindler Elevators, KONE Elevators, Mitsubishi Elevators, Fujitec Elevators, Hitachi Elevators, Toshiba Elevators, Fuji Elevators, Express Elevators, Sigma Elevators, LG Elevators, Hyundai Elevators, BLT Elevators, CANNY Elevators, SJEC Elevators, KOYO Elevators
