Passenger Elevator Ventilating Fan

Payment Type: T/T
Incoterm: CFR,CIF,EXW,CPT
Min. Order: 100 Piece/Pieces
Delivery Time: 10 Days

Basic Info

Model No.: EVF-YS-ZFB9B | EVF-YS-ZFB9D

With CE Approval: YES

Additional Info

Packaging: Export Packing Plywood Case

Brand: Powered by CEP Elevator Products

Transportation: Ocean,Land,Air,Courier Service

Place of Origin: Made in CHINA

Supply Ability: Quantity Production

Certificate: EN81, CE, Gost-R, SASO, VOC, KTL, UL, CSA

HS Code: 8431310090

Port: Ningbo,Shanghai

Product Description

Elevator Cross Flow Fan

Elevator Ventilator

Elevator Ventilator Fan

Elevator Ventilation Fan

Elevator Ventilating Fan

Elevator Ventilation System

Elevator Axial Flow Fan

Elevator Axial Fan

Elevator Aerofoil Fan

 Elevator Cross Flow Fan


Motor: Capacitor Induction

Sleeve or Ball Bearing

Impeller: Reinforced Plastic, ø91mm*260mm

Frame: Steel with Electroplate

Service Life: 10,000hours with Sleeve bearing, 30,000hours with ball bearing

Operation Temperature: -20- +50

Weight: 2.6kg

Part No.

Voltage(VAC)

Frequency(Hz)

Current(A)

Power(W)

Speed(RPM)

Air Flow(m3/hour)

Noise(dB)

EVF-YS-ZFB9B/100

100

50/60

0.21/0.23

22/25

1200/1250

245/260

47

EVF-YS-ZFB9B /110

110

50/60

0.23/0.25

24/27

1250/1300

255/270

47

EVF-YS-ZFB9B /220

220

50/60

0.09/0.10

21/24

1260/1370

250/260

47

EVF-YS-ZFB9B /230

230

50/60

0.09/0.11

21/25

1300/1420

260/280

47


Part No.

Voltage(VAC)

Frequency(Hz)

Current(A)

Power(W)

Speed(RPM)

Air Flow(m3/hour)

Noise(dB)

EVF-YS-ZFB9D/100

100

50/60

0.21/0.23

22/25

1200/1250

245/260

47

EVF-YS-ZFB9D/110

110

50/60

0.23/0.25

24/27

1250/1300

255/270

47

EVF-YS-ZFB9D/220

220

50/60

0.09/0.10

21/24

1260/1370

250/260

47

EVF-YS-ZFB9D/230

230

50/60

0.09/0.11

21/25

1300/1420

260/280

47


Elevator Cross Flow Fan



Elevator Cross Flow Fan




We carry high quality Elevator Ventilating Fan
for all major elevator and escalator brands

for OTIS Elevators, ThyssenKrupp Elevators, Schindler Elevators, KONE Elevators, Mitsubishi Elevators, Fujitec Elevators, Hitachi Elevators, Toshiba Elevators, Fuji Elevators, Express Elevators, Sigma Elevators, LG Elevators, Hyundai Elevators, BLT Elevators, CANNY Elevators, SJEC Elevators, KOYO Elevators, IFE Elevators
